Decon E-Drive

From £5,295.00

VAT exempt
Free nationwide assessments, delivery and set-up

The E-Drive is a hub mounted, manual wheelchair power assist for easier everyday flexibility. Choose from user or attendant joy-stick control and simply switch back to manual propulsion as and when desired.

SKU: POWR-SUSS-DECONED Categories: All terrain, All-Terrain Power, Mobility, Power Add-On, Powerchairs, Standard Powerchair, Transportable Powerchairs, Wheelchair Add-On, Wheelchairs Tags: Decon, Lithium Battery, Power Assist, Powered Wheelchair, Transportable, Wheelchair Add-On

Power-assist flexibility

The E-Drive’s two 120w hub motors turn any manual wheelchair into an ultralight powerchair. This is an ideal option when you want to tackle slopes and various terrains, or to save energy when travelling further. It is also as suitable for indoor use as it is with outdoors.

Joystick control

A simple-to-use joystick controller can be placed at the front of a manual wheelchair for user control, or on the handlebars for attendant control. (Left or right mounted.)

An added option allows the front-mounted joystick to swing away for easier access to tables and desks, or extra space for wheelchair transfers if needed.

There are also various joystick tops available to suit your preference.

Good to know

The E-Drive can be mounted on 99% of manual wheelchairs, from tilt-in-space to active wheelchairs, and is compatible with a range of wheel sizes: 16”, 20”, 22”, 24”, 25”, 26”

With quick-release axles, this wheelchair power add-on is easy to remove and suitable for both car and air travel, with a low weight of only 7kg.

Easy-access battery. The E-Drive comes with a Nickel Metal Hydride battery (NiMH) as standard, or you can upgrade to the Lithium-ion battery. Both are IATA approved for air travel.
Maximum battery range: NiMH 10 miles, Li-ion 18 miles
Normal charging time: 2–3 hours
The display on the LCD screen can be seen in sunlight when you’re out and about.

Watch the E-Drive video

Brand

Decon

Technical Specifications

Engine	24V 120Wx2
Battery type	Nickelmetallhybrid, 24Vx6,7 Ah (optional L i-ion, 25Vx11,8Ah)
Weight wheel (1pcs.)	7 kg
Total weight	16 kg (incl NiMH batteri) , 17,5 kg (incl Li-iON batteri)
Wheel dimensions	16”, 20”, 22”, 24”, 25”, 26”
Air pressure	6 Bar, 600 kPa
Speed	0-6 km/h
Max range (with fully charged battery)	24": ca NiMH 16 km, Li-ion ca. 30km. 16": 15 km NimH, 25 km Li-ion
Max userweight	Up to 125 kg
Max userweight “Heavy-duty”	Up to 150 kg
Max gradient	6 degrees
Joystick	Contactless sensing of single-chip
Lever resistance change	Lever springs with different resistance levels
Display	LCD (Visible in sunlight)
Program parameters	Joystick or computer (Smart Tune)
Battery charger	100 to 240V AC, 50/60Hz
Power rating	37V. 26A (while charging)
Charging time	Normal charging ca. 2-3 hours
